Working power:DC 5V power supply or 18650 battery(need to bring your own)
Applicable battery:meet the stop discharge voltage 2.5~3.5V,2.8V start~4.2V full battery is applicable
Power supply interface:Type-C interface,power supply line self-provided(C port mobile phone line)
System language:Chinese(default),English
Number of tests:1-way charging and discharging measurement(only the right battery bit)
Internal resistance measurement:Yes,the internal resistance is tested by DC two-wire method
Charging function:support,full charge automatic cut off charging(do not support lithium iron phosphate battery charging)
Discharge function:support,automatic stop when the condition is reached,discharge current is not adjustable
Auto charge & discharge:yes,the battery is fully charged at the end of Auto mode
Cycle charging and discharging: support,1~9 cycles adjustable(only supported in automatic mode)
Status tip:yes
Stop discharge voltage:2.5V,2.6V,2.7V,2.8V,2.9V,3.0V,3.1V,3.2V,3.3V,3.41V,
3.5V total of 11 adjustable steps
Discharge current:two resistors,up to about 1A current,non-adjustable,do not support independent transformation
Charging voltage:special battery charging chip control,up to about 1A charging,full voltage 4.2V
Net weight:80g
Package weight:120g
Size:110mm*88mm*30mm
Package weight:153*100*42mm
