Rated input:AC 20A
Rated output:AC 10mA
Rated sampling resistance:100Ω
Rated sampling voltage:AC 1V
Accuracy level:0.1
Normal current:AC 0~80A(RL≤80Ω)
Maximum current:AC 0~120A(RL≤10Ω)
Secondary internal resistance:146±10Ω
Net weight of product:25g
High permeability amorphous nanocrystalline magnetic core:high permeability, high saturation magnetic induction intensity, high working temperature, can continuously work at 120 ° C, low coercivity, low loss, low magnetostriction coefficient, excellent thermal stability
High quality OA-155 enameled wire:Use high-quality enameled wire with good insulation, high conductivity, and long service life
