Description
Output power:100mW
Audio frequency response range:50Hz-18KHz
Transmitting frequency:76.0MHz-108.0MHz(configure the transmitting frequency through the computer)
Modulation mode:Standard FM frequency modulation
Sound channel:Mono
Supply voltage:DC 3.0V-5.0V operating current:35mA
Transmitter antenna:75cm rod antenna
Transmitting distance:FM transmitting module connected to the 75cm standard rod antenna,radio with Delsun PL-660,open space measured coverage radius of 100 meters.Measured coverage radius 100 meters.(Note:Transmitting distance is for reference only,due to the use of different environments vary slightly)
Product Features:
1:Using advanced FM phase-locked loop modulation technology(PLL) to make the sound quality more realistic.
2.Adopting audio-specific low-noise operational amplifier,with extremely low power consumption and minimal noise interference.
3.Power-down automatically memorizes the frequency before power failure.
4.The temperature and voltage change the transmitter frequency no longer drift.
5.Frequency output is accurate,adjustable range is wide.
