Description
Package:PCB package
Interface:golden finger interface
Core:RISC-V Dual Core 64bit,with FPU
Main frequency:400Mhz(can be overclocked to 600Mhz)
SRAM:Built-in 8M Byte
Image recognition:QVGA@60fps/VGA@30fps
Speech Recognition:Microphone Array (8mics)
Network model:support YOLOv3/Mobilenetv2/TinyYOLOv2/face recognition,etc.
Deep learning framework:support mainstream frameworks such as TensorFlow/Keras/Darknet/Caffe
Peripherals:FPIOA,UART,GPIO,SPI,I²C,I²S,TIMER
On-board resources and interfaces:DVP camera interface,128MbitFlash,most |0 are led out by golden finger,which is convenient for secondary development
Size:25.0*22.0mm
Supply voltage:5.0V @300mA(supply current must be greater than 300mA)
Working temperature:-30℃ ~ 85℃
