Description
Usage:
1. Pulse data sampling for electricity meters
2. Fax machine shredder paper detection
3. Obstacle detection
4. Black and white line detection
Module feature:
1. Using TCRT5000 infrared reflection sensor
2. Detection reflection distance:1mm~25mm applicable
3. Comparator output, clean signal, good waveform, strong driving ability, exceeding 15mA.
4. Equipped with multiple adjustable precision potentiometers to adjust sensitivity
5. Working voltage:3.3V-5V
6. Output form:Digital switching output (0 and 1)
7. Equipped with fixed bolt holes for easy installation
8. PCB size:3.2cm×1.4cm
9. Weight:3.3g
10. Using a wide voltage LM393 comparator
