Temperature range :-50-110℃
Size: 48 * 40mm
Temperature control mode: ON / OFF
Resolution: When temperature is 0.1℃, the resolution is -9.9~99.9, other temperature segment is 1℃
Control accuracy: 0.1 ℃
Hysteresis accuracy: 0.1℃
Refresh rate: 0.5S
High temperature protection: 0-110℃
Supply voltage: AC 110V-220V
Static current: ≤ 35MA, attract current ≤ 65MA
Output voltage: AC 110V-220V
Output power: 10A relay
Measurement input: NTC (10K 0.5%) Waterproof Sensor
Environmental requirements: -10 ~ 60 ℃ ,Humidity 20% -85%
Note: Transformer power module is 300MA
