Input voltage:4-35V
Output voltage:1.25-25V continuously adjustable(default shipping voltage 4.2V current 1A,need it voltage can be adjusted by itself)
Adjustment method:first connect the input power supply correctly(between 4-35V) and then use a multimeter to monitor the output voltage and adjust the potentiometer(generally turn to boost and buck counterclock)
Output current:12V to 5V max 2A(output other voltage,calculate current according to 15W,formula 15/output voltage=output current)
Output power:15W max(if the temperature is high,please strengthen the heat dissipation)
Conversion efficiency:80% the higher the output voltage,the higher the efficiency)
Operating temperature:industrial grade(-40℃ to +85℃ ambient temperature over 40℃,please reduce power usage,or enhanced heat dissipation)
Full load temperature rise:45℃
Indicator:constant current indicator is red,the indicator is red during charging,and the indicator light is blue after charging
Output short circuit protection:yes
Wiring:it can be soldered directly to the PCB
