Description
1. Minimum rated working voltage: DC4.5 5V-24V
2. Maximum operating current: 15 mA (DC 5V)
3. Working voltage range: DC 5～18 V
4. Load capacity: ≤10 mA (DC 5V)
5. Operating temperature range: ≤80℃
6. Operating humidity range: 35%～90%RH (no frost)
7. Allowable pressure: water pressure below 1.75Mpa
8. Storage temperature: -25～+80℃
9. Storage humidity: 25%～95%RH
10.Lead-out method:
Red - IN: connected to the positive pole
Yellow - OUT: signal output line
Black - GND: connected to negative pole
Product Features:
1.This product has a light and flexible appearance,small size,and is easy to install
2.The impeller is embedded with a stainless steel shaft,which is always wear-resistant
3.The sealing ring adopts the structure of upper and lower force and never leaks
4.The Hall element is imported from Germany and encapsulated with potting glue to prevent water ingress and never age
5.All raw materials meet ROHS testing standards
