Description
Product Parameters:
Model:STM32F103C8T6
Kernel:ARM32 bit ortet-M3CPU
Size:22.86mm×53.34mm
Debugging method:SWD
Product Introduction:
This is a core chip based on the STM32F103C8T6 (domestic model benchmarking this model) ARM core board, with the following functions:
1. The motherboard is based on the most basic MCU circuit, 8M and 32768 crystal oscillator circuit, and USB power supply circuit
The core board is divided into two rows, leading to all I/O ports
3. It has a SWD simulation debugging download interface, which is simple, convenient, and fast for debugging
4. Using the TYPE-C interface, it can be used for USB communication and power supply. The USB interface is compatible with ordinary Android phone charger interfaces.
5. Equipped with double row pins, default not welding, users can choose the welding direction suitable for their own application scenarios
Interface Description:
1. SWD interface: supports simulation, download, and debugging
2. TYPE-C USB interface: Power and USB communication, download not supported
3. USART1 interface: USART1 can be used to download programs or communicate using USART 1
4. MCU pin interface: Lead out all I/O port pins for easy connection with peripherals
5.5V and 3.3V power input and output interfaces: commonly used for external power supply or grounding together with other modules for processing
